Size : 25 NB – 100 NB (1″ – 4″)
-
Type : 2-Way
-
Pressure Rating : Class 150
-
Operating Temp. : upto 180 deg C
-
Process Connection : Screwed End / Flanged End / True Union
-
Leakage Class : Class IV
-
MoC : UPVC / CPVC
-
Duty : Modulating / ON-OFF / 3 Point Control
-
Pneumatic Pressure : 4-6 Barg
-
Signal : ON/OFF – 220VAC / 24VDC
Modulating – 4~20 mA / 0-10 VDC -
Accesories : Solenoid Valve, Limit Switch, Positioner, Manual Override, 3 Point Control
-
Applications : Chemical Plants, Acid Plants, Pharmaceutical Plants, Water Treatment Plants
Description
-
Reliable & Cost Effective
-
Best Quality
-
Light in weight
-
Asthetically designed
-
Mounting dimensions follows to ISO5211 standard
-
Comparatively Longer life
-
Large size indicator provides better position indication from a distance
-
Stroke Adjustment about +/-5% is possible
-
Lowest delivery period
Specifications
Ball Valve
-
Size : 25NB to 100NB (1″ to 4″)
-
Type : 2-Way
-
Body : UPVC / CPVC
-
Disc : UPVC / CPVC
-
Seat : PTFE
-
Pressure Rating : Class 150
-
Temperature : upto 180 Deg C
-
Connection : Screwed End / Flanged End / True Union
-
Leakage Class : Class IV
Pneumatic Actuator
-
Body : Aluminium alloy
-
Torque : 10Nm to 9000Nm
-
Pneumatic Pressure : 4 – 6 Barg
-
Mounting : ISO5211
-
Position Indicator : Mechanical Position indicator
-
Rotation Angle : 0 to 90° (Rotary Type)
-
Rotation Angle : Mechanical Position indicator
-
Stroke Adjustment : +/- 5% of 90 deg
-
Ambient Temperature : -30° C to +60° C
Accessories
Solenoid Valve – ON/OFF Duty
-
Type : Namur 3/2 & 5/2
-
Coil : 220 VAC / 24 VDC
-
Protection : IP65 / Flame Proof
Positioner – Modulating Duty
-
Type : Electro-Pneumatic / Smart
-
Signal : 4~20 mA / 0-10 VDC
-
Feedback : 4~20 mA / 0-10 VDC (Optional)
Manual Override – Manual Operation along with Automatic
-
Type : Mechanical
-
Lever : Available for De-clutching the Actuator control
Limit Switch – Position Feedback
-
Type : Mechanical / Proximity Switch
-
Signal : Potential Free in case of Mechanical Switch
24VDC in case of Proximity Switch -
Enclosure : Aluminum
-
Protection : IP 67
