Size : 15 NB – 80 NB (1/2″ – 3″)
-
Type : 2-Way
-
Pressure Range : 0 – 7 Barg
-
Operating Temp. : upto 180 deg C
-
Process Connection : Screwed End / Flanged End
-
MoC : SS304 / SS316
-
Duty : ON-OFF
-
Coil : Metallic / Plastic Body
-
Coil Voltage : 220 VAC, 24 VDC
-
Power Consumption : 8W @220VAC / 11W @24VDC
-
Protection : IP68, Flameproof
-
Environment Temp. : 0 to 70 deg C
-
Media : Water, Steam, Air, Gas, Oil
-
Application : Water ATM, Commercial Boilers, Utilities, Water Treatment, Compressors, LPG Supply
Description
-
Reliable & Cost Effective
-
Best Quality
-
Light in weight
-
Asthetically designed
-
Available in all grade of Stainless Steel
-
Comparatively Longer life
-
No Corrosion
-
Can be used at outdoor applications
-
Lowest delivery period
Specifications
-
Size : 15 NB – 80 NB (1/2″ – 3″)
-
Type : 2-Way
-
Pressure Range : 0 – 7 Barg
-
Operating Temp. : upto 180 deg C
-
Process Connection : Screwed End – BSP / NPT Threads
Flanged End -
MoC : Body – SS304 / SS316 / Brass (available on demand)
Diaphragm – NBR / EPDM / Viton / PTFE -
Duty : ON-OFF
-
Coil : Metallic / Plastic Body
-
Coil Voltage : 220 VAC, 24 VDC
-
Power Consumption : 8W @220VAC / 11W @24VDC
-
Protection : IP68, Flameproof
-
Environment Temp. : 0 to 70 deg C
-
Media : Water, Steam, Air, Gas, Oil
-
Application : Water ATM, Commercial Boilers, Utilities, Water Treatment, Compressors, LPG Supply
