Size : 25 NB – 100 NB (1/2″ – 4″)
-
Type : 2-Way
-
Pressure Rating : Class 150
-
Operating Temp. : upto 180 deg C
-
Process Connection : Screwed End / Flanged End / True Union
-
Leakage Class : Class IV
-
MoC : UPVC / CPVC
-
Duty : Modulating / ON-OFF
-
Electrical Supply : 220 VAC / 24 VDC
-
Signal : ON/OFF – 220VAC / 24VDC
Modulating – 4~20 mA / 0-10 VDC -
Accessories : Manual Override
Position Feedback Card -
Applications : Chemical Plants, Acid Plants, Pharmaceutical Plants, Water Treatment Plants
Description
-
Reliable & Cost Effective
-
Best Quality
-
Light in weight
-
Asthetically designed
-
Mounting dimensions follows to ISO5211 standard
-
Comparatively Longer life
-
Large size indicator provides better position indication from a distance
-
Aux. Contacts for potential free feedback
-
Self-Locking due to worm-worm gear mechanism
-
Space Heater
-
Lowest delivery period
Specifications
Ball Valve
-
Size : 25 NB – 100 NB (1/2″ – 4″)
-
Type : 2-Way
-
Body : UPVC / CPVC
-
Ball : UPVC / CPVC
-
Seat : PTFE
-
Pressure Rating : Class 150
-
Temperature : upto 180 deg C
-
Connection : Screwed End / Flanged End / True Union
-
Leakage Class : Class IV
Electrical Actuator
-
Enclosure : Aluminium alloy
-
Torque : 30Nm to 50000Nm
-
Electrical Supply : 220 VAC, 24 VDC
-
Control Signal : ON/OFF – 220VAC / 24VDC
Modulating – 4~20 mA / 0-10 VDC -
Motor : Squirrel Cage Induction Motor (AC)
Brushless Motor (DC) -
Duty Cycle : S2 (15-30 min)
-
Limit Switch : 1 x SPDT (220VAC, 10A) for each Open / Close
-
Manual Override : Wrench Type / Handwheel
-
Space Heater : 7-10W (220VAC) to remove moisture in enclosure
-
Cable Entry : 2 X M18
-
Operating Conditions : -20 to 70 deg C, 80-90% Humidity
-
Mounting : ISO5211
-
Position Indicator : Mechanical Position indicator
-
Rotation Angle : 0 to 90° (Rotary Type)
